Wall Panel Structure Chain Drive High Speed Metal Door And Window Roll Forming Machine

A new type of bottom drive door frame forming machine(door frame roll forming machine/ window frame roll forming machine), comprising a forming module and a cutting module, inside the said forming module, there is a left-hand guide frame on the top surface of the fixed table, the right-hand side of the said left-hand guide frame is a bending forming area, a plurality of lower forming rollers are set up in the bending forming area by means of two support plates set up in front and rear, and a plurality of upper forming rollers are fixed directly above each lower forming roller; on the said support plate, (door jamb roll forming machine/window jamb roll forming machine)there is an opening slot set up for each lower forming roller, and a movable plate is fixed vertically in each opening slot by means of a pressure plate, and a plurality of upper forming rollers are fixed together by means of two movable plates in front and rear. The support plate is provided with an opening slot for each lower forming roller, and a movable plate is fixed vertically in each opening slot by means of a pressure plate, and the two corresponding movable plates at the front and rear are jointly erected with an upper forming roller; a drive gear is provided at the front or rear end of each lower forming roller, and the lower forming roller is driven by meshing between the drive gears or by a chain drive; the forming module is provided with a The top of the forming module is provided with a shaping module on the right side of the bending and forming area, said shaping module is provided with a plurality of shaping rolls set up and down for shaping the sheet after bending; (metal door roll forming machine/metal window roll forming machine) said cutting module includes a fixed frame, said fixed frame has a plurality of vertical drives fixed vertically on the top, said each vertical drive is provided with a punching top die on the bottom, each punching top die is provided with a punching bottom die directly below a punching base is provided, said punching base being fixed to a fixed base plate. (door panel roll forming machine/(door panel bending machine)

Flow Chart of Wall Panel Structure Chain Drive High Speed Metal Door And Window Roll Forming Machine

5T hydraulic decoiler-Roll forming machine-Hydraulic cut-Outer table

Main Technical Parameters

Pictures of Wall Panel Structure Chain Drive High Speed Metal Door And Window Roll Forming Machine

LINBAY MACHINERY we are located in Wuxi city, Huishan District which is known for the quality of its steel and fine craftsmanship. Our factory has 2 machining center work shop, two assembling workshop and 2 profile producing work shop. In total, our factory covers an area of 10,000 ㎡. Our main production is roll forming machine, specially cable tray roll forming machine, strut channel/Solar photovoltaic stents roll forming machine, din rail roll forming machine, highway guardrail W beam/thrie beam roll forming machine, wire mesh fence post roll forming machine, scaffolding plank roll forming machine, upright rack roll forming machine, box beam roll forming machine, step beam roll forming machine, steel frame roll forming machine and roof panel roll forming machine. We are founded in 2012, we almost have 10 years production experience, however our boss and our design engineers have been working over 20 years in this machine and have been over to more than 80 countries to install our equipment. We are being the most professional manufacturer of roll forming solutions.

As always we are focus con the machine for customized profiles and special profiles, and will do all we can to make this business relationship a success. With 10 years’ experience, the smallest profile that we have made is smaller than a pen, the precision that we have met is just +/-0.1mm, the run-out range of the rollers is only +/- 0.03mm, also we succeeded in making a 90°roof panel profile. We make unremitting efforts to satisfy our customers with the profile that other supplier aren’t able to do.

Our secret to producing this such high-precision roll forming machine is that we use Germany application Copra to make our design and 3D simulation function to ensure the profile. Besides, our factory has its own production line, from punching molds to forming rollers, each mechanical part is completed independently by our factory self. We strictly control the accuracy at each step from design, processing, assembling to quality control, we refuse to cut corners.

Our sales department is also excellent. We are proficient in machine knowledge. Our sales engineers can give the best offer for our customers according the requirement and budget. In addition to speaking English, we also have salesman who speaks Spanish and other speaks Russian. Our customers are mainly in USA, Middle East, Latin America, Russia, and some Asian countries. We know well the requirements of customer who has high-standard with his machine, and we offer it and make it perfect. About the quality, we are confident to give 2 years for whole production line 5 years for rollers and shafts as warranty period. If there will be any quality problems caused by non-human factors, we will handle it totally for free for you, so that you will have no worries after sales.

Our company has a wealth of experience and qualifications. We have CE certificate to export to European countries, we have ISO certificate to cooperate with Saudi customers for SABER certificate to facilitate customs clearance, our equipment meets HQTS standards and can provide COI certificate for export to Iraq, our equipment meets Canadian standards and can provide CSA certificate.

LINBAY is trusty and responsible and we are your first choice of roll forming machine.
